- Graphical display – 240×160 pixel readout with up to 6 views, user programmable
- Accurate billing – redundancy digital output 90º/180º for billing or dosing control
- Custody transfer – CT approved system to OIML R117
- Dosing control – direct control of one or two on/off valves, or one analog valve for dosing applications
- Alarms & safety – advanced diagnosis and service menu enhances troubleshooting and validation
- Alarm handling – choice of Siemens or NAMUR standard configurations (NE21 and NE43)
- SensorFlash allows simple sensor replacement and data transfer into existing transmitter
- Digital signal transfer and 100 Hz update rate to all outputs
Detail
Architecture
|
Compact or remote configuration
|
|
---|---|---|
Communication
|
Profibus DP/PA 4.0, Modbus RS485, HART 7.2
|
|
EMC performance
|
EN 61326-3-2
|
|
Material
|
Aluminium with corrosion-resistant coating
|
|
Enclosure rating
|
IP67
|
|
Mechanical load
|
18 to 1000 Hz random, 3.17 G rms, in all directions
|
|
I/O
|
Up to 4 channels combining analog, relay or digital outputs and binary input
|
|
Display
|
Full graphical display, 240 x 160 pixels
|
|
Power supply
|
24 to 90 V DC, 100 to 240 V AC
|
|
Approvals
|
Hazardous areas Hygenic approvals |
ATEX, IECEx, FM, NEPSI, CSA, EAC EHEDG Complying with NAMUR OIML R 117 |
Certificates
|
Compact system SITRANS FC430
|
SIL 3
|
Typical applications: Chemical process industry, oil & gas industry, automotive industry and ower generation & utility industry.
