- Testing, adjustment and calibration of all types of pressure gauges
- 3 in 1: vacuum, low pressure and medium pressure calibration
- Exact setting in the mbar range thanks to the ultra-fine thread pitch and large-volume control valve
- Tool-free change between overpressure and vacuum generation
 Datasheet |
- Testing, adjustment and calibration of all types of pressure measuring instruments
- 3 in 1: Vacuum, low pressure and medium pressure calibration
- exact setting in the mbar range thanks to ultra-fine thread pitch and large-volume regulating valve
- tool-free changeover between overpressure and Vacuum generation
- only pneumatic hand test pump up to 60 bar
| Datasheet |
- Pressure range: 0 to 40 bar (600 psi)
- Vacuum range: 0 to -900 mbar (28.5 inHg)
- High pneumatic pressure generation with minimal effort
- Precision fine adjustment with vernier control
- Dual source for pneumatic pressure and vacuum
- Built-in fine adjustment vernier
- Needle valve for controlled pressure release
- Selector valve for vacuum or pressure generation
- Comfortable, ergonomically designed molded handles
- Adjustable stroke
- Extremely efficient – only four strokes to reach 7 bar (100 psi)
 Datasheet
|
- Pneumatic (operated with ambient air)
- Making pressure up to +60 bar (870 psi)
- Making vacuum down to -0,95 bar (-28 inHg)
- Bench type
- Very easy operation, fine volume adjustment
|
Datasheet
|
- Pressure up to -0,75 bar
- Precision needle valve
- Fine dosing valve
- Heat insulating
- Private labelling possible
|
Datasheet
|
- Reach: approximately 5 bar
- Very precise pressure control
- Precision needle valve
- Heat insulating material
- Private labeling possible
|
Datasheet
|
- Testing, adjustment and calibration of all types of pressure gauges
- long-term stable measurements without pressure drop due to hermetically sealed vacuum chamber
- exact setting in the mbar range thanks to ultra-fine thread pitch and large-volume regulating valve
- tool-free changeover between overpressure and vacuum generation
- smallest mobile hand test pump on the market
|
Datenblatt
|
- Pressure range: 0 to 40 bar (600 psi)
- Vacuum range: 0 to -900 mbar (28.5 inHg)
- High pneumatic pressure generation with minimal effort
- Precision fine adjustment with vernier control
- Dual source for pneumatic pressure and vacuum
- Built-in fine adjustment vernier
- Needle valve for controlled pressure release
- Selector valve for vacuum or pressure generation
- Comfortable, ergonomically designed molded handles
- Adjustable stroke
- Extremely efficient – only four strokes to reach 7 bar (100 psi)
|
Datasheet
|
- Pneumatic pressure up to 1250 in H2O / 45 psi
- Vacuum up to -27 in Hg
- Precise fine adjustment down to 0.01 in H2O
- Thermally insulated to eliminate temperature effects
| Datasheet |
- Switchable pressure/vacuum generation
- Precise setting through the fine adjustment valve
- Simple and ergonomic handling
- Compact dimensions
- Low weight
| Datasheet |
| User Manual |
- Ergonomische Handhabung
- Präzise Einstellung durch Feinregulierventil
- Kompakte Abmessungen
- Geringes Gewicht
|
Datenblatt
|
|
Bedienungsanleitung
|
- Hydraulic pressures up to 10,000 psi
- Pneumatic pressures up to 600 psi
- Vacuum up to 28.5 in Hg
- Low pressure fine control
- Unique vacuum priming function removes trapped air during hydraulic operation
- High pressure generation achieved with volume adjuster – no physical effort required
- Pressure/vacuum selector valve provides fine pressure relief in pneumatic and hydraulic modes
- Tamper-proof overpressure protection valve adjustable from 300 to 10,000 psi
- Removable hydraulic reservoir can be detached without fluid drainage
- Reservoir safety feature with spring-loaded top cover vents above 8 psi
- Hydraulic mode designed for use with distilled water and/or high-viscosity mineral oil
- Highly sensitive volume adjuster for use across hydraulic, pneumatic, vacuum and low pressure modes
- Built-in stroke adjuster controls pressure/vacuum per stroke
- 240° swivel head for optimal reference viewing
- Internal moving parts PTFE anodized to reduce friction and wear
- Ergonomic, rugged, and lightweight design with comfortable hand grip
|
Datasheet
|
![Model CPP140-M Pneumatic comparison test pump To 140 bar [2,000 psi]](https://www.ics-schneider.de/wp-content/uploads/2025/08/cpp140-m-350x350.jpg?x34852)
- Simple handling
- Pneumatic pressure generation to 140 bar [2,000 psi]
- Knurled nut for easy and optimal positioning of the measuring instruments
- Precise setting of the test pressure through a fine adjustment valve
- Pressure connections with quick-release connector and knurled nut
| Datasheet |
| User Manual |
- Portable, only 5.7 lb
- Great stability and high resolution
- Minimal maintenance
- Hand-tight quick connectors
|
Datenblatt
|
|
Bedienungsanleitung
|
- Generate 2000 psi (140 bar) in 30 seconds
- Minimal maintenance
- Hand-tight quick connectors
- First one in the world
| Datasheet |
- Generate 3,000 psi (200 bar) in 40 seconds
- Minimal maintenance
- Hand-tight quick connectors
- First one in the world
|
Datenblatt
|
|
Bedienungsanleitung
|
| Pressure range | [bar] | to+100 bar, switchable to vacuum to -0.95 bar |
| Medium | ambient air | |
| Pressure ports | 2 x 1/2" BSP female rotating swivel nut (2 adapters to M20x1.5 female are included in delivery) | |
| Pressure fine adjustment | Fine adjustment valve, sensitivity ±0.1 mbar | |
| Dimension | [mm] | 450 x 262 x 170 |
| Weight | [kg] | 5,6 |
| Design | Manual lever pump with fine adjustment and pressure/vacuum-switch | |
| Order-Code | ISP-100-P |
|
Datasheet |
Pneumatic Calibration Pumps – Precise Vacuum & Pressure by Hand
Pneumatic calibration pumps generate vacuum and pressure without auxiliary power—ideal for field service, commissioning, and the lab. Depending on the model they cover −0.95 bar up to 20–60 bar and provide fine adjustment valves, fine volume control, and venting for stable, repeatable settings. Combined with reference gauges/sensors they form compact mobile calibration kits.
ICS Schneider Messtechnik supplies hand and bench pumps, matching references, adapters & hoses, seal kits, and DAkkS/ISO calibration—optionally as a complete service case.
FAQ on Pneumatic Calibration Pumps
Answers on selection, pressure ranges, stability, connections, tightness, media, and best practices.
What are pneumatic calibration pumps suitable for?
For generating and finely adjusting vacuum/overpressure when calibrating transmitters, pressure switches, and gauges—especially mobile and clean because there is no oil in the system.
What pressure ranges are typical?
| Range | Typical value | Use |
|---|---|---|
| Vacuum | down to approx. −0.95 bar | Pressure switches, leak tests |
| Overpressure | up to approx. 20–60 bar | Process/service calibration |
| Fine steps | mbar/Pa range | Low pressure, HVAC, lab |
How do they differ from hydraulic pumps?
Pneumatics are clean and fast but reach lower maximum pressures. Hydraulics offer very high pressures and maximum stability but require a medium (oil/water).
How do I achieve a stable reading?
- Use fine volume/micro adjust
- Keep it short: minimize hose length & dead volume
- Tight fittings, avoid temperature drift
Which connections are common?
| Thread | Standard | Note |
|---|---|---|
| G 1/4 / G 1/2 | ISO 228 | Industry standard, flat sealing possible |
| 1/4" NPT | ASME | Tapered, sealing compound required |
| Quick coupling | — | Fast DUT changeover |
Which references pair well?
Digital reference gauges or reference transmitters with suitable range/accuracy (e.g., ≤ 0.1% FS)—including DAkkS/ISO certificate for traceability.
How do I run a leak test?
Drive to the setpoint, isolate, then log pressure decay over a defined time. Consider ambient effects (temperature, volume).
Are there combo pumps for vacuum & overpressure?
Yes. Many hand pumps offer a switch between vacuum and overpressure—ideal for service and commissioning.
Which accessories are useful?
- Adapter sets (G/NPT, various sizes)
- Seal kits (NBR/FKM/PTFE) for tight connections
- Gauge/sensor holders, hoses, carrying case
How often should I calibrate the reference?
Typically annually (usage dependent). After shocks/overload, check immediately.
What safety aspects apply?
- Respect the maximum pressure of pump, hoses, and adapters
- Never disconnect under pressure; wear eye protection
- Use only clean, dry air/N₂
Tips for very low pressures (mbar/Pa)
Minimize dead volume, use ultra-fine valves, allow stabilization time, and shield the setup from drafts.
Do you supply complete calibration kits?
Yes—consisting of pump, reference, adapters/hoses, seals, and optional documentation templates (CSV/PDF).
