- Pressure ranges from 25 mbar to 700 bar (10 inH₂O to 10,000 psi)
- Single or dual-range sensor configuration
- mA measurement, switch test, and 24 V loop power supply
- Large backlit display with intuitive, menu-driven interface
- Integrated HART® resistor for digital communication
- Robust and weatherproof design
- Compact, user-friendly, and easily portable
- Convenient one-handed operation with secure grip and impact-resistant elastomer protection
- Plug-and-play compatibility with universal pressure modules (IUPM/IUPMP), accuracy up to 0.05% FS (total) or 0.01% FS (precision)
- Programmable leak test for automatic leak rate detection
- Advanced functions including hold, min/max/average values, alarm, and tare for efficient troubleshooting
 Datasheet |
| User Manual |
- Pressure ranges from 25 mbar to 700 bar (10 inH₂O to 10,000 psi)
- Single or dual-range configuration available
- Simultaneous measurement of pressure and mA for calibration and maintenance of transmitters and control loops
- 24 V loop power supply for energizing transmitters and control loops
- Automatic switch test for rapid and accurate detection of switching points
- Integrated, selectable HART® resistor (250 Ω) for easy communication with HART devices
- Large backlit display with intuitive, menu-driven operation
- Robust and weatherproof housing designed for demanding conditions
- Compact, user-friendly, and easily portable
- One-handed operation with secure grip and impact-resistant elastomer protection
- Plug-and-play compatibility with universal pressure modules (IUPM/IUPMP), accuracy up to 0.05% FS total or 0.01% FS precision
- Programmable leak test for automatic measurement of pressure drop and leak rate
- Advanced features: hold, min/max/average values, alarm, and tare for efficient troubleshooting
| Datasheet |
| User Manual |
- Sources and measures mA, mV, V, ohms, frequency, and pulses
- Simulates and measures 8 RTD and 12 thermocouple types
- 32 available pressure modules from 25 mbar to 700 bar (10 inH₂O to 10,000 psi)
- Simultaneous dual-reading capability
- Automatic switch test and pressure leak test
- Data storage for 1000 measurement points with real-time clock
- 24 V loop power supply
- Integrated HART® loop resistor
- Large backlit display
- Robust and weatherproof
- Compact, user-friendly, and easily portable
- Convenient one-handed operation
- Plug-and-play connection for universal IDOS pressure modules
| Datasheet |
- Current Calibrator 0/4 - 22mA, Source/Sink
- Voltage Calibrator 0-14V
- mV Ranges 0-28mV and 0-560 mV
- DIN Thermocouples J, K, N, R, S, T, B, E
- Multimeter ±2V to ±200V DC and ±100mA
- Simultaneous Calibration and Measurement
- Steps, Ramps, direct entry
- Built-in rechargeable Battery
 Datasheet |
- Current Output 0-22mA, Source/Sink
- Voltage Output 0-25V
- mV Outputs 0-27mV and 0-540 mV
- DIN Thermocouples J, K, N, R, S, T, B, E
- RTD Simulator -200 … 850ºC
- Resistance Range up to 3kOhm
- Multimeter ±2V to ±200V DC and ±100mA
- Measurements of fast Transients
- Datalogger Function (Option)
- 8 Tables with each 50 free Output Points
| Datasheet |
| Measuring counts | |
| TRMS | |
| AC/DC voltage | 1000V anche AC+DC |
| AC/DC current | 1A anche AC+DC |
| Resistance and buzzer continuity | |
| Diode test | |
| Frequency | |
| DC 4-20mA current measurement | |
| DC 0-10V voltage measurement | |
| DC 4-20mA current generation | |
| Measurement of output current of transducers | |
| Simulation of an external transducer | |
| Loop supply with minimum voltage 24V | |
| Generation of selectable ramp | |
| Load of 250Ω for testing HART transducers | |
| Backlit LCD display | |
| Autorange | |
| Auto Power OFF | |
| Data HOLD | |
| MIN/MAX function | |
| AVG function | |
| Relative measurement | |
| Protection category | CAT IV |
| Weight in grams (batteries included) | |
| Size (LxWxH) (mm) |
|
Datasheet
|
| Measuring counts | |
| TRMS | |
| AC/DC voltage | MAX 10VDC |
| AC/DC current | MAX 24mADC |
| DC 4-20mA current measurement | |
| DC 0-10V voltage measurement | |
| DC 4-20mA current generation | |
| DC 0-10V voltage generation | |
| Measurement of output current of transducers | |
| Simulation of an external transducer | |
| Loop supply with minimum voltage 24V | |
| Generation of selectable ramp | |
| Backlit LCD display | |
| Auto power off | |
| Protection category | |
| Weight in grams (batteries included) | |
| Size (LxWxH) (mm) |
|
Datasheet
|
The compact, simple-to-use C.A 1621 thermocouple temperature calibrator is capable of measuring and simulating up to 8 types of thermocouples, as well as a voltage in mV. When used as a battery-powered stand-alone instrument, it offers a long battery life in the field. When connected to the mains, it can be used continuously without any time limit!
|
Datasheet
|
Compact and simple to use, the C.A 1623 calibrator is capable of measuring and simulating up to 7 different probes as well as a resistance. When used as a battery-powered stand-alone instrument, it offers a long battery life in the field. When connected to the mains, it can be used continuously without any time limit!
|
Datasheet
|
Compact and simple to use, the C.A 1631 calibrator is equipped with a wide screen for comfortable reading.. The C.A 1631 can be used to measure and supply a DC current loop from 0 to 24 mA with 0.015% accuracy and a DC voltage between 0 and 20 V with an accuracy of +/- 0.02 %. When used as a battery-powered stand-alone instrument, it offers a long battery life in the field. When connected to the mains, it can be used continuously without any time limit!
|
Datasheet
|
- Sourcing, simulating and measuring pressure, temperature and electrical signals
- Built-in Barometer
- Intrinsically safe models available (Ex)
- Large Smartphone like touchscreen user experience
- USB Type-C and Bluetooth communications
- IP67 Rated
- High Voltage Measurement Capability (±300V AC)
- True RMS Voltage Meter Capability
- Dual channel pressure module ports
- High Static Differential Pressure Measurement 0.002% FS
- ISO 17025-accredited calibration w/data included
| Datasheet |
- Sourcing, simulating and measuring pressure, temperature and electrical signals
- Built-in Barometer
- Intrinsically safe models available (Ex)
- Large Smartphone like touchscreen user experience
- USB Type-C and Bluetooth communications
- IP67 Rated
- High Voltage Measurement Capability (±300V AC)
- True RMS Voltage Meter Capability
- Dual channel pressure module ports
- High Static Differential Pressure Measurement 0.002% FS
- ISO 17025-accredited calibration w/data included
| Datasheet |
| ATEX Certificate |
- Sourcing, simulating and measuring pressure, temperature and electrical signals
- Built-in Full Hart Communicator (ADT227-HART)
- Built-in Barometer
- Intrinsically safe models available (Ex)
- Large Smartphone Like Touchscreen User Experience
- USB Type-C and Bluetooth communications
- IP67 Rated
- High Voltage Measurement Capability (±300V AC)
- True RMS Voltage Meter Capability
- Dual channel pressure module ports
- High Static Differential Pressure Measurement 0.002% FS
- ISO 17025-accredited calibration w/data included
| Datasheet |
- Sourcing, simulating and measuring pressure, temperature and electrical signals
- Built-in Full Hart Communicator (ADT227-HART)
- Built-in Barometer
- Intrinsically safe models available (Ex)
- Large Smartphone Like Touchscreen User Experience
- USB Type-C and Bluetooth communications
- IP67 Rated
- High Voltage Measurement Capability (±300V AC)
- True RMS Voltage Meter Capability
- Dual channel pressure module ports
- High Static Differential Pressure Measurement 0.002% FS
- ISO 17025-accredited calibration w/data included
| ATEX Certificate |
| ATEX Certificate |
- Accuracy to 0.01% of reading
- Measure, source, or simulate loop current
- Measure DC volts
- Simultaneously mA and % span display
- Switch functionality
- Selectable ramp and step functions
- HART 250Ω resistor in series with 24V loop
- ISO 17025-accredited calibration w/data included
| Datasheet |
| User Manual |
- Measuring and Sourcing loop current, mV, and V
- Measuring and sourcing simultaneously
- Loop integrity check capability
- 24V loop supply with simultaneous current measurement
- Three year warranty
- ISO 17025-accredited calibration w/data included
| Datasheet |
- Sourcing, simulating and measuring, temperature and electrical signals
- Smartphone-like menu and interface make the operation simpler and easier
- The internal cold junction compensation sensor can be re-calibrated at ice point by users
- Ultra-compact, 3.9” x 7.6” x 2.0”, and 1.6 lb (0.7 kg)
- ISO 17025-accredited calibration w/data included
| Datasheet |
- Sourcing, simulating and measuring pressure, temperature and electrical signals
- Smartphone-like menu and interface make the operation simpler and easier
- The internal cold junction compensation sensor can be re-calibrated at ice point by users
- Ultra-compact, 3.9” x 7.6” x 2.0”, and 1.6 lb (0.7 kg)
- ISO 17025-accredited calibration w/data included
|
Datasheet
|
- Measurement and simulation of the following parameters: pressure, electrical signals (mA, mV, V, Ω), temperature (TC, RTD), frequency and pulse
- Large colour touchscreen display with new intuitive and user-friendly interface
- Internal pressure/vacuum generation
- Option: intrinsically safe version, II 2G Ex ib IIC T4 Gb - Tamb: -10 ... +50 °C
- Option: integrated HART® module for communication with HART® instruments
|
Datasheet
|
|
User Manual
|
|
User Manual
|
|
User Manual
|
- Selectable transducer output sensitivity
- Standard 6 pin Bendix connector
- 5 step linear output 0 – 100%
- Identifies faulty components in a measurement loop
| Datenblatt |
| Bedienungsanleitung |
