Dose rate measuring system GRAETZ X5C plus


  • Calibratable dose rate meter for the measurement of gamma and X-ray radiation for the measurand Ḣ*(10) ambient dose equivalent rate.
  • Detector: Energy-compensated Geiger-Müller counter tube
  • Large digital measured value display on LC display (illuminable)
  • Optional dose rate or dose display with integration time
  • Additional quasi-analog display of dose rate (3.5 decades, logarithmic bar display)
  • Display of the dose rate peak value and the dose rate mean value
  • 4 freely programmable dose and dose rate warning thresholds
  • Automatic and manual storage of dose rate readings together with date and time
  • Dwell time/residual time determination
  • Switchable acoustic single pulse detection
  • Menu-driven operator guidance, partially password-protected
  • Storage of the set parameters even when the device is switched off or the battery is changed
  • High reliability due to test function and continuous self-monitoring
  • Metallized plastic housing, well decontaminable, protection class IP67
  • RS-232 interface
  • Can be combined directly or via probe cable with various probes (see brochure “Probe program”):
    • Measuring range extension up to 10 Sv/h –
    • For the detection of α-, β- and γ-radiation
    • For fluid testing
    • For measurements in hard-to-reach places
    • DE telescopic probe for measurements from a safe distance
    • Scintillation probe 2002 for measuring low dose rates
  • In custody transfer applications, the probes of the GRAETZ “CE” program are used
Datasheett
Datasheet SE
Add to your Quote List

The dose rate measuring system GRAETZ X5C plus has a dose display as well as a warning function for personal radiation protection when handling ionizing radiation. The GRAETZ X5Cplus is PTB type-tested and can therefore be calibrated. The measuring system is also equipped with an RS-232 interface and an interface for connecting external probes.

  • Calibratable electronic dose rate measuring system in compact and robust design
  • Approval for use by fire departments
  • Extension of the measuring range by interface for external probes
  • Dust and splash protection as well as protection against short-term immersion in water (protection class IP67)



Technical Data

Display ranges Dose
 0.01 µSv ≤ H*(10) ≤ 10 Sv
Dose rate 0 nSv/h ≤ Ḣ*(10) ≤ 19.99 mSv/h
Measuring ranges Dose 0.5 µSv ≤ H*(10) ≤ 10 Sv
Dose rate 1 µSv/h ≤ Ḣ*(10) ≤ 19.99 mSv/h
Dimensions approx. 152 × 82 × 39 mm
Weight (incl. batteries) approx. 385 g



Embodiments

Dose rate measuring system GRAETZ X5C plus SE

  • Special version of the PTB type-approved X5C plus in a non-calibratable variant
  • Product Data Sheet Dose Rate Measurement System GRAETZ X5C plus SE in short description
