Datasheet
The DSP-HW 2 is a voltage detector for checking flooded cellars, industrial facilities and electrical installations. By quick and easy testing, the operation sites are checked for electrical hazards and the emergency services are protected.
The voltage tester for flooded areas fulfils the requirements of the trade association GS-ET-43, the accident prevention regulation for fire brigades GUV-V C53 and has been highlighted by the VDE committee “Safety and Accident Research” as a safety gain.
Fully automatic measuring sequences and only one button eliminate operating errors. Its integrated self-test enables quick functional testing on site without further testing equipment. The robust and IP 65 waterproof design distinguishes the voltage monitor.
The DSP-HW 2 may only be used after product training has been completed. Also by electrotechnical non-professionals.
COMPLIANT WITH STANDARDS:
- fulfills the requirements of the professional association GS-ET 43 “voltage tester water”
- meets the requirements of the accident prevention regulation DGUV 49
- meets the requirements of the accident prevention regulation fire brigades GUV-V C53
- CE compliant: Low Voltage Directive 2014/35/EU | EMV Directive 2014/30/EU | ROHS Directive 2011/65/EU | WEEE Directive 2012/19/EU
- surge voltage resistance according to EN/IEC 60071
- voltage limits AC 25 V / DC 40 V according to GS-ET 43 “voltage tester water”
FIELD OF APPLICATION:
- optimized for use in flooded electrical systems and flooded maintenance shafts
- before use product training required (can also be used by electrical non-professionals)
- simple and quick handling
- versatile use by testing with or without a handle and sensor ball
VOLTAGE TESTER:
- clear LED indication for dangerous voltage red / green
- warning and display of the voltage AC 25 V – 1000 V / DC 40 V – 1500 V
- voltage proof – CAT IV 600 V / CAT III 1000 V
- illuminated display
SELF-TEST:
- integrated self-test to check the display, battery, connection cable and grounding
- RDY to indicate operational readiness
- constant self-monitoring
FURTHER FUNCTIONS:
- stable housing with impact-resistant display cover
- 30 m long earthing line to reach every location
- insulation fault detection due to two-color cable insulation
- IP 65 – waterproof display
TECHNICAL DATA
| DSP-HW 2 | SET DSP-HW 2 | |
|---|---|---|
| Nominal voltage | 12 – 1000 V AC 12 – 1500 V DC |
|
| Display range | 12 – 1000 V AC 12 – 1500 V DC |
|
| Field of application | flooded basements, underground garages and electrical systems
flooded maintenance and elevator shafts objects protruding into the water such as banisters |
|
| Selftest | yes
testing of the line, grounding and measurement technology |
|
| Voltage warning by red / green LED | yes | |
| Voltage warning by LCD | yes | |
| Voltage warning by acoustic signal | no | |
| Frequency range | DC / 16 – 500 Hz | |
| Power supply | 9 V battery with multi-level battery display, can be changed by the user at any time |
|
| Overvoltage category | CAT IV 600 V | |
| Degree of protection | IP 65, water proof | |
| Standard | requirements of the professional association „Spannungswarner Wasser“ GS-ET-43 based on EN/IEC 61243-3 Fire brigade accident prevention regulations Impulse voltage resistance according to EN/IEC 60071 CE conformity according to the Low Voltage Directive 2014/35/EU |
|
| Scope of delivery | voltage warning device DSP-HW 2 waterproof manual |
voltage warning device DSP-HW 2 waterproof manual bag Ground spike 400 mm clamp for pole |
| Bag for storage | no | yes |
| Art.-no. | 81347 | 81348 |
| Product packaged dimensions and weight | 330 x 200 x 240 mm
2500 g |
370 x 200 x 260 mm
4,300 kg |
