Technical data
Pressure connection
External thread G 1/2 (pressure gauge connection) to DIN 16 288 and internal
thread G 1/4 to ISO 228 Part 1.
Switching device
Rugged housing (200) made of seawater resistant die cast aluminium.
Materials
Pressure bellows: Material no. 1.4571
Sensor housing: Material no. 1.4104
Switch housing: GD AI Si 12
according to DIN 1725
Mounting position
Vertically upright and horizontal.
Ambient temperature at switching device
–20 to +70°C.
Medium temperature –20 to +70°C.
The maximum medium temperature at the pressure sensor must not exceed the permitted ambient temperature at the switching device. Temperatures may reach 85°C for short periods. Higher medium temperatures are possible provided the upper limit at the switching device is ensured by suitable measures (e.g. siphon).
Mounting
Directly on the pressure line (pressure gauge connection) or on a flat surface with two
4 mm Ø screws.
Calibration for maximum pressure switch The pressure monitors and safety pressure limiting devices are calibrated so that, under rising pressure, switching takes place at the defined switching pressure. The reset point under falling pressure is lower by the amount of the switching differential, or, in the case of pressure limiting devices, by the fall in pressure specified in the table. The scale value corresponds to the upper switching point.
Component tested for |
|
||||
Testing basis | VdTÜV Memorandum “Pressure 100” | ||||
Function | Pressure monitor / Pressure limiter | ||||
Directing of action | For maximum pressure monitoring only | ||||
Sensor | “Of special construction” (self monitoring sensor with safety diaphragm) |
Max. permissible pressure | Dimensioned drawing | ||||||
Type; | Setting range | Switching differential | |||||
(Tolerance) | |||||||
Pressure monitors without differential adjustment for max. pressure monitoring* | |||||||
S. 21+22 | |||||||
DWAM06! | 0,1…0,6 bard | i 20 … 50 mbar | ; 5 bar | ||||
DWAMI i | ;0,2…1,6 bar | ;20 … | 80 mbar | 5 bar | LI | + 15; | |
DWAM6j | 1,2 .., 6 bar | 0,1 … 0,26 bar | 10 | bar | |||
DWAM625 | ; 1,2…6 bar | 0,13 .,. 0,31 bar | 20 | bar | |||
DWAM16; | ;3…16 bar | 0,2 … 0,6 bar | |||||
DWAM32 | 6…32 bar | 0,6 … 1,6 bar | 45 bar | ||||
Pressure monitors with differential adjustment for max. pressure monitoring | |||||||
DWAMV1 | bar; | 0,12…0,6 bail | ;5 bar | ||||
1 | +15 | ||||||
r DWAM1f6 | ; 1,2 .. 6 bar | bar; | 10 | bar | |||
DWAMV16; | ;3…16 bar | 0,8..,2,5 bar | 20 | bar | |||
1 | +1J | ||||||
;DWAMV32; | ; 6…32 bar | ; 2,5_6,0 bar | 45 | bar | |||
Pressure limiters for maximum pressure monitoring (with internal interlock) | |||||||
Pressure Change | |||||||
for unlocking | -0- | ||||||
;SDBAM1; | ;0,2…1,6 bar; | .0,12 bar | 5 bar | ||||
;SDBAM2,5 | bar; | 0,18 bar | |||||
SDBAM6; | 1,2…6 bar | ; 0,42 bar | 0 bar; | ||||
SD BAM625 | 1,2…6 bar | 0,6 bar | 0 bar | ||||
SDBAM16 | 3…16 bar | 1,1 bar | 20 bar | 1 | + 19 | ||
DBAM32 | 6…32 bar | 3,0 bar; | 45 bar |
