Datasheet- Surface: steel phosphatized
- Working pressure up to 700 bar (10.000 psi) on request
- External stem thread
- Stem with cold rolled surface, back seat and non-rotating needle tip
- Types with 1/4 NPT thread on request
- The valves can be supplied according to NACE-standard
On request: – Anti-tamper facility - Panel mounting
- Extended body on male inlet port
- Padlocking facility
1) Can also be supplied for oxygen service.
Please notice order instruction B 3!
2) Available with inspection certificate 3.1.B acc. to EN 10 204
3) Also available with soft tip in KEL-F®
(PCTFE) or Delrin®
(POM) 4) 1.4122 quenched and tempere
