DatasheetProfibus Communication Interface
RS485 Profibus converter, 3 DIN modules according to DIN 43880
| Type | Interface for Profibus communication, RS485 Profibus conversion |
|---|---|
| Function | RS485 Profibus conversion with input, output and supply insulation |
| Format | 3 DIN modules according to DIN 43880 |
| Profibus standard | Profibus EN50170 |
| Baud rate | Up to 1.5 Mb |
| Required response time | ≤ 10 ms |
| Address | 1…127 |
| Address setting | Via DIP switches |
| Max. distance from master | According to standard |
| Rated voltage | 18…35 VDC / VAC |
| Power consumption | ≤ 3 VA |
| Installation category | III |
| Pollution degree | 2 |
| Test voltage | 1 kV R.M.S., 50 Hz / 1 min |
| Impulse withstand voltage | 800 V, 1.2/50 µs, 0.5 J |
| Test circuit | Input, output, auxiliary supply |
| Auxiliary supply connection | Screw terminal for wires up to 2.5 mm² |
| RS485 communication connection | Screw terminal for wires up to 2.5 mm² |
| Profibus communication connection | SUB-D, 9-pin |
| Mounting | Snap-on mounting on 35 mm DIN rail |
| DIN rail type | TH35-15 according to EN60715 |
| Housing material | Self-extinguishing polycarbonate |
| Weight | 150 g |
