DatasheetFunctions
| TRMS | |
| Measuring counts | 10000 |
| DC/AC TRMS voltage up to 1000V | 1000V / AC+DC |
| DC, AC TRMS, AC+DC TRMS current by means of external clamp transducer | |
| AC TRMS current by means of external flexible transducer F3000U | |
| Leakage current with optional clamp meter | |
| Electric motor starting current (INRUSH) | |
| Insulation with voltage 50, 100, 250, 500, 1000VDC | According to IEC/EN61557-2 |
| Continuity of protective circuit with 200mA | According to IEC/EN61557-4 |
| Voltage and current harmonics up to the 25th and THD% | |
| LoZ Input | |
| Frequency | |
| Phase sequence | |
| Out come OK/NOT OK | According to IEC/EN60364-6 |
| Resistance and continuity test with buzzer | |
| Bargraph | |
| Backlit LCD display | |
| MAX/MIN/HOLD | |
| Measurement category | CAT IV 600V / CAT III 1000V |
| Weight in grams (batteries included) | 420 |
| Size (L x W x H) | 175x85x55 |
Guidelines
- CEI 64-8
- IEC/EN61010-1
- IEC/EN61010-2-030
- IEC/EN61010-2-033
- IEC/EN61326-1
- IEC/EN61557-1
- IEC/EN61557-2
- IEC/EN61557-4
- IEC/EN61557-7
- UNE20460
