Datasheet- Optional hinged vane for low density materials and small process connections
- Five seal ingress protection
- Motor switches off during alarm for long service life
- Friction clutch design prevents impact damage
- Rotation failure monitoring
- Ideal for extreme conditions including high temperature and buildup
- Rotatable enclosure for ease of installation
Detail
|
Range
|
100 mm to 10 m (4 inch to 30 ft)
|
|---|---|
|
Process Temperature
|
-25 to 600 °C (-13 to 1112 °F), higher temperatures upon request
|
|
Process Pressure
|
Up to 10 bar g (145 psi g)
|
|
Bulk densities
|
Starting at 15 g/l (0.9 lb/ft³) with optional vane
|
|
Versions available
|
Compact, rigid extended, cable extended, angle extended
|
|
Options
|
Functional Safety (SIL 2). Device suitable for use in accordance with IEC 61508 and IEC 61511 Fail-safe configuration High-temperature model Extension kit (cable or rigid) Universal power supply |
|
Key Applications
|
Bulk solids such as grain, feed, cement, plastic granulate, wood chips
|
