Nemo D4-b – Network monitor for Low voltage 4 module

Multifunction module for measurement acquisition in low-voltage networks
Suitable for single-phase networks and 3-/4-wire three-phase networks with unbalanced load
Three-phase network 80…600 V phase-phase, single-phase network 50…350 V phase-neutral
Current input 1 A or 5 A via external current transformers
Programmable primary current range from 5 A to 8000 A with 41 ranges
True RMS measurement for reliable measured value acquisition
Backlit LCD with manual or automatic scanning
Compact 4-DIN-module design

Datasheet
User Manual

Multifunction module for low-voltage networks, 4 modules

Type	Multifunction module for electrical measurement acquisition in low-voltage networks
Format	4 DIN modules
Network	Single-phase network and 3-/4-wire three-phase network, unbalanced load
Three-phase network	80…600 V phase-phase, direct connection
Single-phase network	50…350 V phase-neutral
Current input	1 A or 5 A, connection to external current transformers
Primary current range	Programmable primary current 5…8000 A, 41 ranges
Measuring method	True RMS measurement
Display	Backlit LCD, manual or automatic scanning
Output	Without output
Auxiliary supply	115 VAC or 230…240 VAC or 400 VAC
