VariAS-Blocks Flange x Flange
AS-Schneider VariAS-Blocks are designed to replace conventional, multiple-valve installations and are close coupled to the process piping flange, for connecting process to instruments. The primary isolation valve needs to be of process design. Primary and Secondary Isolation Valve are, as standard, ball type valves with floating ball, the bleed valve can be provided as needle type valve with screwed bonnet as well as ball type valve with a 3-way T-Port ball. Process and Instrument Connections are provided, as standard, with Flange Connections acc. to ASME B 16.5.
The VariAS-Blocks are available as Single Block & Bleed or Double Block & Bleed designs. The VariAS-Blocks are available with Bore Size 10, 14 and 20 mm.
 Datasheet |
