Datasheet| Type | 2224.2 |
| brief data | 0 – 48VDC / 0 – 3.5A |
| description | DC Voltage Regulator |
| input voltage | 230VAC 50-60Hz |
| Input/output separation | galvanically isolated, unearthed |
| output voltage | 0… 48VDC |
| output current | 0… 3.5A |
| output current duration | |
| output power | 168W |
| continuous power | 168W |
| short-term resilience | 168W |
| CV Stability Load 0-100% | 70mV |
| CV residual ripple Ueff | 2mV |
| settling time | 100µs |
| no-load current consumption | |
| connection input | 3-pole mains cable with Euro safety plug |
| connection output | Apparatus terminals 4mm, screwable and pluggable |
| Device Properties | Linear regulator with automatic operating mode changeover CV/CC, temperature monitoring, voltage and current regulation, short-circuit proof, carrying handle |
| cooling | controlled fan cooling |
| Weight | 7.0 |
| casing | desktop case |
| Dimensions | 260x150x230 |
| Degree of protection/class | IP30/I |
| color | Front RAL 7035 light grey, body RAL 7036 platinum grey |
| Stability Ua with change Ue | |
| Others | ground socket |
