2225.5 – DC voltage regulator

2x(0 – 24VDC / 0 – 10A)

Datasheet

Type	2225.5
brief data	2x(0 – 24VDC / 0 – 10A)
description	DC Voltage Regulator
input voltage	230VAC 50-60Hz
Input/output separation	galvanically isolated, unearthed
output voltage	2x 0… 24VDC
output current	2×0… 10A
output current duration
output power	2x240W
continuous power	2x240W
short-term resilience	2x240W
CV Stability Load 0-100%	50mV
CV residual ripple Ueff	1mV
settling time	200µs
no-load current consumption
connection input	3-pole mains cable with Euro safety plug
connection output	Apparatus terminals 4mm, screwable and pluggable
Device Properties	Linear regulator with automatic operating mode changeover CV/CC, temperature monitoring, voltage and current regulation, short-circuit proof
cooling	controlled fan cooling
Weight	14
casing	desktop case
Dimensions	360x150x230
Degree of protection/class	IP30/I
color	RAL 7035 light grey
Stability Ua with change Ue
Others	ground socket
