PRÜFBALL SPB DIGITAL – Robust voltage tester up to 1000 V AC / DC


The Prüfball Digital is a maintenance-free voltage and continuity tester for the power supply and industry. Protected by its unique rubber housing, the Prüfball is indestructible, safe and durable.

The Ball SPB Digital combines state-of-the-art microcontroller technology with the proven features of the analogue test ball
-accurate, robust, maintenance-free.

Datasheet
User manual
Add to your Quote List

Voltage tester:

  • precise display of the voltage 50 V – 1000 V AC/DC / 50 V – 500 V AC/DC
  • extremely resistant to voltage – CAT IV 1000 V – VDE certified
  • clear LED indicator for dangerous voltage
  • load connection for interference voltages and RCD tripping
  • full voltage indication without battery – maintenance free
  • large LCD display with backlight

Continuity tester:

  • fast continuity test
  • continuity test with display up to 1000 kOhm

Phase and phase sequence tester:

  • phase tester with indication “POL” and red LED
  • rotating field tester with LCD display left / right
  • controller-monitored test with error detection to avoid false indications
  • phase and phase sequence tests can also be performed with insulating gloves

More functions:

  • safety housing made of solid rubber extremely shockproof
  • test electrodes with thread for screwing on accessories
  • easy operation
  • insulation fault detection by two-color cable insulation
  • extremely stable housing, even in cold environment
  • IP 65 – waterproof



SPB 500L SPB 1000L
Nominal voltage 50 – 500 V AC / DC 50 – 1000 V AC / DC
Dispaly range 24 – 500 V AC / DC 24 – 1000 V AC / DC
Continuity measurement 0 – 1000 kOhm
(50 kOhm steps)
Continuity tester with sound no
Frequency DC / 15 – 2 000 Hz
Single pole outer conductor test (Phase) yes
Phase sequence test yes
Phase sequence test for IT-power grids without earth potential no
Power supply maintenance-free – voltage test without battery,
continuity test with Long-Life lithium battery
Overvoltage category CAT IV 500 V
CAT IV 1000 V
Protection category IP 65
VDE GS certification in accordance with IEC 61243-3 yes
Measuring point illumination no
Additional load and 30 mA RCD-tripping yes
Adjustable electrode length 4 or 15 mm yes, by protective cap
Art.-No. 81422 81423
Product
Dimensions and weight		 274 x 75 x 47 mm
(display part)

415 g
Packed Product
Dimensions and weight		 315 x 105 x 60 mm

470 g
