Datasheet| Type | 2218.6 |
| brief data | 60VDC / 12VDC 5A |
| description | DC-DC converter |
| input voltage | 50VDC – 70VDC |
| Input/output separation | no galvanic isolation |
| output voltage | 12VDC stabilized |
| output current | 5A |
| output current duration | |
| output power | 60W |
| continuous power | 60W |
| short-term resilience | 60W |
| CV Stability Load 0-100% | 25mV |
| CV residual ripple Ueff | 8mV |
| settling time | 3ms |
| no-load current consumption | 35mA |
| connection input | Flat plug 6.3 mm |
| connection output | Flat plug 6.3 mm |
| Device Properties | Electronic overload protection, can be switched in parallel, overvoltage protection, undervoltage shutdown |
| cooling | convection |
| Weight | 0.75 |
| casing | Wall mounting, mounting bracket |
| Dimensions | 150x85x65 |
| Degree of protection/class | IP 30 |
| color | RAL 7035 light grey |
| Stability Ua with change Ue | 20mV |
| Others | Common negative pole not connected to housing, operating temperature -5…35°C |
