IDAC180 dynamic pressure measurements for extreme pressure peaks


  • nominal pressure range 0 … 8000 bar
  • operating temperature °C -50 … 200
  • sensitivity pC/bar 2.3
  • natural frequency kHz > 240
  • mechanical connection M10x1.0
  • excellent long-term stability
Datasheet
User Manual

The piezoelectric pressure sensor was developed for detecting dynamic pressure changes up to 8000 bar in hydraulic systems. The unique GaPO4 sensor element allows a sensitivity of 2.3 pC/bar. It is therefore ideal for resolving small pressure fluctuations across the entire pressure range. The front-sealing sensor in conjunction with the compression fitting is not influenced by either installation or installation position.









Technical advice: 03303 / 50 40 66

Technical advice for this product
