DatasheetIMPROVED PERFORMANCE
The LMI6000 Series marks a new generation in usability, accessibility, and performance. A new electromechanical lift automates the placement of weights. In addition, a larger, adjustable, and repositionable touchscreen, improved hardware architecture, and software automation make test execution with the push of a button more convenient than ever.
ADVANCED SOFTWARE
Tests can now be run without manually lifting weights thanks to the electromechanical lift, which also allows for simultaneous testing on multiple devices.
The integration of the lift increases user safety by reducing repeated weight handling and also improves accuracy through automated loading and unloading of weights.
The IoT-capable software of the LMI6000 allows connection to the Dynisco IoT Cloud Console for direct access to your test data.
This platform also enables correlation of lab data with production data from the line via cloud connection.
Material certification traceability is greatly simplified and can be accessed at any time globally via PC, smartphone, or tablet.
INCREASED ACCESSIBILITY
A new hardware architecture also provides faster and more intuitive navigation. The dedicated front power switch ensures that all data is saved before shutdown.
The larger, side-mounted touchscreen offers a better user experience with flexible left or right mounting and adjustable height for optimal operator comfort.
FEATURES
- Gravitational Correction is enabled on the LMI6000 (see manual).
→ Gravitational forces vary in countries near the equator such as Malaysia, Indonesia & India. - Windows 10 IoT Touchscreen Interface
- Performance Meets International Standards:
ASTM D1238 & D3364, ISO 1133-1, BS2782, DIN 53735, JIS K7210 - Built-in WiFi and Ethernet Connectivity
- Improved Die Access through strategically placed mirror – easier view of the die and cutting area
- Automatic Sample Cutter for consistent and easy sample cutting
- Intrinsic Viscosity (IV) Measurement standard on all devices
- Multi-language Interface:
English, German, French, Spanish, Portuguese, Italian, Dutch, Polish, Czech - Printing and Flash Storage Option Available
- External Scale Connection:
Customers can connect Dynisco’s high-resolution 3-digit scale to the LMI6000 via one of the 4 USB ports on the unit
LMI6000 SERIES OPTIONS
DYNSICO IoT CLOUD CONSOLE
Dynisco’s IoT Managed Service offers customers comprehensive access to rheological data, correlations, and dashboards.
The native IoT software of the LMI6000 enables connection to the Dynisco IoT Cloud Console for direct data transfer.
This allows lab test results to be correlated with production data from rheometers connected to Dynisco’s IoT Cloud.
This simplifies lot traceability and material certification—data is accessible globally at any time via PC, smartphone, or tablet.
DIGITAL ENCODER
The digital encoder enables volumetric measurement of piston displacement during A/B and B test methods.
AUTOMATIC SAMPLE CUTTER
The automatic sample cutter cuts samples according to Method A and A/B.
The “waste cut” end piece is also cleanly removed, ensuring more repeatable and accurate samples compared to manual cutting.
SINGLE OR MULTI-WEIGHT STACK VERSIONS
The unit can be configured as a single or multi-weight system.
The automated weight system is more ergonomic, safer, and efficient and reduces operator error during multiple weight testing.
PERFORMANCE CHARACTERISTICS
| Technical Feature | Specification |
|---|---|
| Compliant Standards | ASTM D1238 & D3364, ISO 1133-1, BS2782, DIN 53735, JIS K7210 |
| Operating Temperature | Ambient to 400 °C |
| Temperature Control | ±0.1 °C |
| Digital Encoder Accuracy | ±0.025 mm over 25.4 mm |
| Communication | 4× USB, PC connectivity, scale interface, printing & flash storage |
| Weights | Range of 0.325 kg to 31.6 kg |
| User Interface | 10.2″ color display with capacitive touchscreen |
DIMENSIONS
| Feature | Value |
|---|---|
| Overall Dimensions | 18″ W × 21″ D × 51″ H (46 cm W × 54 cm D × 130 cm H) |
| Weight | 152 lbs (69 kg) without weights 31.6 kg full stack ASTM 21.6 kg full stack ISO |
| Shipping Weight (incl. weights) | 300 lbs (136 kg) |
| Shipping Orientation | LMI6000 with lift ships horizontally |
ELECTRICAL SPECIFICATIONS
| System Voltage | 100–120 V AC, 50/60 Hz or 220–240 V AC, 50/60 Hz |
| Power | Max. 500 W, typically 100 W at set point |
