The pressure transmitter IP115 is an application-optimized submersible probe that is especially suitable as an OEM component. Various electrical connection options allow for easy integration. The protection class IP 67 reliably prevents dust and water from entering the device. The ceramic sensor operates according to the piezoresistive principle and in combination with the stainless steel process connection forms a robust and compact sensor. Our modular design concept provides a wide variety of products. Feel free to contact us if you need a customization that is not listed in this datasheet.
Applications:
|
Technical data:
| Measuring ranges | Smallest measuring range: 0…100 mbar |
| Largest measuring range: 0…300 mbar | |
| Analog output | 4…20 mA, 2-wires |
| Power supply | 9…30 V DC |
| Accuracy | ≤ ± 0,5 % FS @ 25 °C |
| Long term stability | ≤ ± 0,5 % FS / Year |
| Response time | 200 ms – others on request |
| Swich-on time | < 1 s |
| Temperature coefficient | Zero: ≤ ± 0,03 % FS / Kelvin |
| Span: ≤ ± 0,02 % FS / Kelvin | |
| Medium temperature | -25…100 °C |
| Surrounding temperature | -25…80 °C |
| Storage temperature | -40…85 °C |
| Short-circuit resistance | Permanent |
| Reverse polarity protection | Protection against reverse polarity, but no function |
| Electromagnetic compatibility | Interference emissions and immunity acc. to EN 61326 |
| Wetted materials | Process connection: Stainless steel 1.4404 |
| Sensor: Ceramic Al2O3 | |
| Sensor seal: FPM (Viton), NBR, EPDM, FKKM (Chemraz / Kalrez) | |
| Protection type | IP 67 |
| Weight | Approx. 200 g |
