DatasheetKey features
Saves you time, money, and solvent
- Small sample volume of 2 mL to 3 mL
- 10 times faster measurement than manual methods like pycnometers (ASTM D70)
- Low solvent consumption for cleaning routines
- Quick cleaning routines
Compliant and reliable results
- New automatic bubble detection: FillingCheck™ ensures correctly reported results
- ASTM D4052 and ASTM D5002 compliant
- Fast and new viscosity correction
- Reliable tool for density measurement at elevated temperatures and pressures
Strong and fast U-tube
- High chemical resistance to sour gas, hydrochloric acid, and hydrofluoric acid
- No risk of corrosion and breakage
- Patented Pulsed Excitation Method for fast measurement (AT 516420 B1)
- Made of Hastelloy C276, an alloy that is more robust than stainless steel
Quality control of petroleum samples
- From upstream to downstream
- On incoming crude oil
- On intermediate and process samples to give a quick feedback on the refining process
- For converting volume to mass when trading asphalt/bitumen
- Replaces pycnometers and hydrometers
Suitable for density studies in research
- Determination of equation of state
- Calculation and configuration of production processes
- Pressure-volume-temperature (PVT) analysis of crude oil
- Bubble-point determination of crude oil
- The fast and accurate alternative to pressure hydrometers and pycnometers
Technical specifications
| Patent granted | AT 516420 B1 |
| Measuring range Density Temperature |
0 g/cm³ to 3 g/cm³ -10 °C to 200 °C (14 °F to 392 °F) |
| Pressure range | 0 bar to 500 bar (7250 psi) |
| Accuracy* Density Temperature |
0.0002 g/cm³ 0.03 °C (0.05 °F) |
| Repeatability, s.d.** Density Temperature |
0.00005 g/cm³ 0.01 °C (0.02 °F) |
| Reproducibility, s.d.** Density |
0.0001 g/cm³ |
| Digital Resolution | 0.00001 g/cm³ |
| FillingCheck™ | Yes (at ambient pressure and up to 150 °C) |
| Full range viscosity correction | Yes (at ambient pressure) |
| Temperfect™ | Yes (at ambient pressure) |
| Pulsed Excitation Method | Yes |
| Minimum sample volume | 2 mL |
| Wetted materials | Hastelloy C276 |
| Footprint | 510 mm x 330 mm (20 in x 13 in) |
| ASTM standards | D4052, D5002 |
| Power supply | AC 100 to 240 V, 50 to 60 Hz, 250 VA |
| Connections | Pressure fittings for metal tubes with 1/8″ outer diameter |
| Interfaces | 4 x USB (2.0 full speed), 1 x Ethernet (100 Mbit), 1 x CAN Bus, 1 x RS-232, 1 x VGA |
*this is valid under ideal measuring and sample conditions only (at ambient pressure)
**this is valid under ideal measuring and sample conditions only (at ambient pressure), according to ISO 5725
